H14 High Efficiency HEPA Filter

Availability:
Quantity:

H14 High Efficiency HEPA Filter


Characteristic:

Low resistance

Light bodyweight, convenient installation and alternative

Long life-span

100% manufacturing area inspection

Good sealing

Super high efficiency


Application:

Air cleaners.

Final or return purification for clean rooms having turbulent flow.




Model

Dimensions(mm)

W×H×D

Rated air flow

m3/h

Initial Resistance

(pa)

Efficiency

%





HP

305×305×35

610×610×35

915×610×35

305×305×50

610×610×50

915×610×50

305×305×69

610×610×69

915×610×69

305×305×80

610×610×80

110

450

680

180

700

1100

250

1000

1500

300

1300





≤160





99.99


Frame

Galvanized/Aluminum

Sealant

Polyurethane adhesive

Separator

Thermosol

Media

Fiberglass paper

Max. operating temperature

800C

Max. operating humidity

80%

Sealed material

Neoprene/polyurethane
