Element
● Made of higher strength continuous filament fiberglass, arranged evenly and orderly
● It's a very high collecting efficiency
● Initial resistance of fluffy fiberglass silk cotton is little
● The formaldehyde content is under international standard of the baby underwear
● The generation process is unique, exterior is encrypted, and middle structure is three-dimensional help support
Application
The fiberglass cotton is usually coiled or cut into pieces to produce customers. It can possibly be framed in metal ( gal sheet or aluminum )
Weather purification of high temperatures places in various industrial sectors Oil and paint air filtration for industrial and also civil use.
Technical Parameters
Model | PA-50/60 | PA-100 |
Weight | 240g/㎡ | 320g/㎡ |
Filter Efficiency | 92%-96% | 97%-99% |
Initial resistance | 15Pa | 20Pa |
Final resistance | 250Pa | 280Pa |
Air velocity | 0.7-1.5m/s | 0.7-1.75m/s |
Dust Holding Capacity | 3200-3600g/㎡ | 3600-4900g/㎡ |
Maximum temperature | 170℃ | 170℃ |
Thickness | 50/60mm | 100mm |
Width | 0.8/1.0/2.0m | |
Note: other specifications can be customized according to demand |
